H.265 128CH 4K 5MP 16 SATA HDD 640M incoming bandwidth intelligent analysis function NVR for security project

Name: H265 128CH 4K 5MP 16 SATA HDD 640M incoming bandwidth intelligent analysis function NVR for security project
Brand: SEEMYT
Price: 700 USD

Quality H.265 128CH 4K 5MP 16 SATA HDD 640M incoming bandwidth intelligent analysis function NVR for security project for sale

Brand Name : SEEMYT

Model Number : SMT-N9016-128CH

Certification : CE/FCC/ROHS

Place of Origin : China

MOQ : 1pcs

Price : USD700-950 per piece

Payment Terms : L/C, T/T, Western Union

Supply Ability : 5000pcs per month

Delivery Time : 5-15 working days for 500pcs

Packaging Details : 1pcs/Carton; Dimension: 685mmX586mmX255mm, 17.35kg

Main Chipset : Hi3536C

Operating System : Embedded Linux

Bandwidth : 640M

Video Format : H.265

Video Resolution : 4K\5MP\3MP\2MP

Smart Functions : Support

Record Mode : Manual, Schedule, Motion Detection, Timing, Alarm, Stop

Playback : 16CH 1080P, 4CH 4K

Backup Mode : USB Device,Network

Video Output : 1 RCA in, 1 RCA out, HDMI audio

Audio Input & Output : 4 in 4 out

HDD : 16 SATA, MAX 8TB HDD

Network Interface : 1*RJ45 10M/100M self-adaptive LAN port

Network Function : DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P

Smart Phone : iPhone, Android

USB : 3 USB Ports(2 USB2.0, 1USB3.0)

Power Supply : DC12V 6.25A

Power Consumption : ATX110-220V 300W 50-60Hz

Dimension : 485mm×545mm×135mm

Weight : 15Kg

Contact Now

Product feature:

• Support corresponding channel of face comparison at the same time
• Support the classification of face recognition black and white lists and triggers various linkage methods
• Support to search for pictures and video files by face
• Support on-site capture, batch import, add face database, preview snapshot interface add face database, add smart snapshot history face database, export face database
• Support HTTP push face image docking and related configuration
• H.265+/H.265/H.264 dual stream decoding, embedded Linux operating system
• Support synchronous recording, remote monitoring, backup; up to 16CH video synchronous playback and multi-channel backward playback
• Support 30min instant playback, 30s pre-record
• Standard ONVIF, SLINK, RTSP protocol
• Support DDNS, EMAIL, UPNP, NTP, P2P and other functions
• Support IE, mobile phone APP, VMS monitoring
• Support external alarm; Two-way audio intercom
• Support our Smart IPC: Target Count,Object Left/Lost, Electric Fence, Line Crossing, Face Grouping List, Face Detection, Humaniod Detection, Retrograde Detection, Leave Position Detection
• Support IPC centralized management, including IPC parameter configuration, information export and import, real-time information acquisition and upgrade, etc.
• Support channel grouping, preview tour
• Support disk grouping quotas and disk group storage modes
• Support double password authentication
• Support network monitoring: network traffic, network delay packet loss test, network packet capture backup
• Support current bandwidth, stream information
• Support HDD hot-swappable
• Support Raid 0,1,5,6,10
• Support offline collection
• Support hot back-up
• Support IPSAN,NAS

Technical parameter:

Main Chipset		Hi3536
Operating System		Embedded Linux
Bandwidth		640M
Video Format		H.265
Video Resolution		4K5MP3MP2MP
Smart Functions		Target Count,Object Left/Lost, Electric Fence, Line Crossing, Face Grouping List, Face Detection, Humaniod Detection, Retrograde Detection, Leave Position Detection (need front end IPC supported)
Record Mode		Schedule, Motion Detection, Timing, Alarm, Stop
Playback		16CH
Backup Mode		USB Device/Network
Video, Audio, Alarm
Video Input		128ch Digital (4000X3000) + 64ch Preview + 16ch Playback + Face Recognition 16ch front end comparision 64ch Digital (4000X3000) + 64ch Preview + 16ch Playback 128ch Digital (4000X3000) + 64ch Preview + 16ch Playback Support import 5000 face database
Video Output		1 HDMI, 1 VGA
Audio Input & Output		1 RCA in, 1 RCA out, HDMI audio
Alarm Input & Output		4 in 4 out
Storage
HDD		16 SATA, Each port supports MAX 8TB HDD
E-Sata		N/A
Network
Network Interface		2*RJ45 10M/100M/1000M self-adaptive LAN port
POE		N/A
Network Function		DDNS,EMAIL,UPNP,NTP,DHCP,IP Filter,PPPoE,P2P
Smart Phone		iPhone, Android
External Ports
USB		3 USB Ports(2 USB2.0, 1USB3.0)
RS232		N/A
RS485		1
Others
Power Supply		ATX110-220V 300W 50-60Hz
Power Consumption		≤50W(without HDD )
Dimension		Equipment :485mm×545mm×135mm Packing :670mmX571mmX226mm
Weight		N.W:14KG (without HDD) with package:15KG
Outside Carton		1pcs/Carton; Dimension: 685mmX586mmX255mm, 17.35kg

H.265 128CH 4K 5MP 16 SATA HDD 640M incoming bandwidth intelligent analysis function NVR for security project

H.265 128CH 4K 5MP 16 SATA HDD 640M incoming bandwidth intelligent analysis function NVR for security project Images
